MODELS & SPECIFICATIONS
It is very important for us to get into a dialog with our customers. As of August 2013 we have 3 solid-body models available. In 2015 we added the AU8, a semi-hollowed model with additional piezo pickups. In 2017 we released the new T8, a semi-hollowed body with a different shaping and single coil pickup combinations and in 2020 the S8 with a 3D-shaped body has been added.
Use the bottom scroll to view the whole table
| U8 | U8 Deluxe | U10 | S10 | T8 | S8 | AU8 | |
| Strings | 8 | 8 | 10 | 10 | 8 | 8 | 8 |
|
Base Price not including VAT, if applicable
|
2.600 € | 5.600 € | 2.700 € | 6990 € | 5.500 € | 6.800 € | 6.990 € |
| Tuners | Touch Guitars® Locking Tuners | Touch Guitars® Locking Tuners | Touch Guitars® Locking Tuners | Touch Guitars® Locking Tuners | Touch Guitars® Locking Tuners | Touch Guitars® Locking Tuners | Touch Guitars® Locking Tuners |
| Bridge | Hipshot bridge with string through body system | Hipshot bridge with string through body system | ABM custom bridge with string through body system | ABM custom bridge with string through body system | Hipshot bridge with string through body system | ABM/Touch Guitars® custom split bridge | Touch Guitars® custom bridge with separate piezo pickups for each string and separate tailpiece |
| String spacing | 10,5 mm | 10,5 mm | 8,5 mm | 8,5 mm | 10,5 mm | 10,4 mm | 10,5 mm |
| Fretboard | maple, ebony or rosewood |
see wood choices We have a big collection of woods available. Please ask about availability. Examples for fretboard wood are walnut, maple, ebony, plumwood
|
maple, ebony or rosewood |
see wood choices We have a big collection of woods available. Please ask about availability. Examples for fretboard wood are walnut, maple, ebony, plumwood
|
see wood choices We have a big collection of woods available. Please ask about availability. Examples for fretboard wood are walnut, maple, ebony, plumwood
|
see wood choices We have a big collection of woods available. Please ask about availability. Examples for fretboard wood are walnut, maple, ebony, plumwood
|
see wood choices We have a big collection of woods available. Please ask about availability. Examples for fretboard wood are walnut, maple, ebony, plumwood
|
| Body type | solid | solid (add 400 € for semi-hollow) | solid | solid (add 400 € for semi-hollow) | semi-hollow | solid | semi-hollow |
| Body material | swamp ash |
see wood choices We have a big collection of woods available. Please ask about availability. Examples for body wood are walnut, maple, korina, plumwood, ash, alder, swamp ash, magogany
|
see wood choices We have a big collection of woods available. Please ask about availability. Examples for body wood are walnut, maple, korina, plumwood, ash, alder, swamp ash, magogany
|
see wood choices We have a big collection of woods available. Please ask about availability. Examples for body wood are walnut, maple, korina, plumwood, ash, alder, swamp ash, magogany
|
see wood choices We have a big collection of woods available. Please ask about availability. Examples for body wood are walnut, maple, korina, plumwood, ash, alder, swamp ash, magogany
|
see wood choices We have a big collection of woods available. Please ask about availability. Examples for body wood are walnut, maple, korina, plumwood, ash, alder, swamp ash, magogany
|
see wood choices We have a big collection of woods available. Please ask about availability. Examples for body wood are walnut, maple, korina, plumwood, ash, alder, swamp ash, magogany
|
| Neck material | 3-piece maple |
see wood choices We have a big collection of woods available. Our necks are usually 3-piece necks. Please ask about availability. Examples for neck wood are mahogany, maple, korina, plumwood
|
3-piece maple |
see wood choices We have a big collection of woods available. Our necks are usually 3-piece necks. Please ask about availability. Examples for neck wood are mahogany, maple, korina, plumwood
|
see wood choices We have a big collection of woods available. Our necks are usually 3-piece necks. Please ask about availability. Examples for neck wood are mahogany, maple, korina, plumwood
|
see wood choices We have a big collection of woods available. Our necks are usually 3-piece necks. Please ask about availability. Examples for neck wood are mahogany, maple, korina, plumwood
|
see wood choices We have a big collection of woods available. Our necks are usually 3-piece necks. Please ask about availability. Examples for neck wood are mahogany, maple, korina, plumwood
|
| Body finish | high gloss solid, burst and transparent |
natural clear, solid and transparent color or sunburst more custom finishing options possible, just ask for it
|
high gloss solid, burst and transparent |
natural clear, solid and transparent color or sunburst more custom finishing options possible, just ask for it
|
natural clear, solid and transparent color or sunburst more custom finishing options possible, just ask for it
|
natural clear, solid and transparent color or sunburst more custom finishing options possible, just ask for it
|
natural clear |
| Straplocks | Jim Dunlop Straplock System | Jim Dunlop Straplock System | Jim Dunlop Straplock System | Jim Dunlop Straplock System | Jim Dunlop Straplock System | Jim Dunlop Straplock System | Jim Dunlop Straplock System |
| Electronics | passive electronics | active 3-band equalizer with parametric mids, Fishman Battery Pack with USB charging | passive, with custom wiring (mono when you are just using one jack) | active with custom 2 band eq for each string set. | passive custom electronics | Darkglass Electronics Tone Capsule (Bass, low-mids, mids) Fishman Battery Pack with USB charging | active custom electronics with separate 2-band equalizer for magnetic and summed piezo pickups, 8-channel mixer for piezo pickups, Fishman Battery Pack with USB charging |
| Pickups |
see pickup options 8-string pickup options: 1. Touch Guitars Modern, 2. Haven Omnia Custom, 3. Lace Alumitone, 4. Cycfi Spectra
|
see pickup options 8-string pickup options: 1. Touch Guitars Modern, 2. Haven Omnia Custom, 3. Lace Alumitone, 4. Cycfi Spectra
|
see pickup options U10 pickup options: 1. Bassculture Modern, 2. Häussel Custom
|
see pickup options S10 pickup is made by Nova Pickups in Germany
|
see pickup options 8-string pickup options: 1. Touch Guitars Modern, 2. Haven Omnia Custom, 3. Lace Alumitone, 4. Cycfi Spectra
|
see pickup options 8-string pickup options: 1. Touch Guitars Modern, 2. Haven Omnia Custom, 3. Lace Alumitone, 4. Cycfi Spectra
|
1 x Cycfi Spectra 8 + custom Graph Tech piezo pickups |
| Controls | volume, passive tone | volume (pull for passive mode), pickup blend, mid frequency, treble, mid, bass | volume , volume | volume , tone, 2-band eq, 3-way switch for each side |
volume 5-way switch, passive tone neck pickup, passive tone bridge pickup Switch positions are: 1. neck humbucker, 2. neck single coil, 3. both humbucker, 4. neck and bridge humbucker in parallel, 5. bridge humbucker
|
volume , 5-way switch, treble, mid, bass Switch positions are: 1. neck humbucker, 2. neck single coil, 3. both humbucker, 4. neck and bridge humbucker in parallel, 5. bridge humbucker
|
volume, pickup blend, bass piezo, treble piezo, bass magnetic, treble magnetic |
| Scale length | 34″ (86 cm) | 34″ (86 cm) | 34″ (86 cm) | 34″ (86 cm) | 34″ (86 cm) | 34″ (86 cm) | 34″ (86 cm) |
| Recommended Tuning | Bb F C G D A C D | Bb F C G D A C D | D G C F Bb | C G D A C | D G C F Bb | C G D A C | Bb F C G D A C D | Bb F C G D A C D | Bb F C G D A C D |
| Country of origin | cnc made in Central Europe | handmade in Austria and Germany | cnc made in Central Europe | handmade in Austria and Germany | handmade in Austria and Germany | handmade in Austria and Germany | handmade in Austria and Germany |
| Output | mono | mono | mono / stereo, automatic switching system | mono / stereo, automatic switching system | mono | mono | mono |
| Other Features | damping fabric on 1st fret (can also be removed if necessary); extremely well balanced (stays in all playing positions); most compact body size | damping fabric on 1st fret (can also be removed if necessary); shaping at contact points with player’s leg and abdomen | amping fabric on 1st fret (can also be removed if necessary); extremely well balanced (stays in all playing positions); most compact body size | damping fabric on 1st fret (can also be removed if necessary); shaping at contact points with player’s leg and abdomen | damping fabric on 1st fret (can also be removed if necessary); semi-hollow offset design with 3D horns | damping fabric on 1st fret (can also be removed if necessary); shaping at contact points with player’s leg and abdomen; 3D shaped curved body | damping fabric on 1st fret (can also be removed if necessary); shaping at contact points with player’s leg and abdomen; custom wooden knobs |
Additional options
Add these options to the base price of the guitar.
All these options are available on the fully handmade models starting from the T8.
- Semi-hollow body – add 400€ (excl. German VAT), T8 is already semi-hollow
- Multiscale – add 500€ (excl. German VAT)
- Neck-thru – add 800€ (excl. German VAT)
- Headless (for S8 and T8) – add 600€ (excl. German VAT)
- Cycfi Multichannel – add 890€ (excl. German VAT) – includes:
- Nu Multi Standard 8 pickup
- Nexus GK Basic Kit
- Lemo Multichannel Cable (right angled jack)
- 19-pin output jack
- 12V Power Supply
- Fishman Battery Pack
With every Instrument you get a free introductory lesson by an experienced member of the Touch Guitar Circle (TGC). The TGC is a study group following a systematic approach to playing the touchstyle technique.
Customization
We offer customization since the instruments are handmade from scratch. Regarding wood choices we recommend two combinations, that is all mahagony or swamp ash with maple neck which sounds a little bit brighter..
Parts
All wood we use is FSC certified, and we are trying to use local European woods in the long term. Each instrument is being hand-built with the person in mind that is going to play it.
We have personal relationships with companies providing labour and parts for our instruments: Our self-designed bridge is made of aluminum and brass by ABM Guitarparts, we use Sperzel locking tuners, the Dunlop Straplok® System, Häussel and Bassculture pickups and electronics by Richter Electronic Engineering.
Please contact our sales team at info@touchguitars.com if you have question or need help.
